Kubota
Kubota 14kW Portable Diesel Generator- GL14000
Highly Resistant to Corrosion
- Description
- Specs
- Downloads
Construction sites for small business contractors and large construction conglomerates alike will love this all-purpose, heavy-duty, commercial-grade diesel generator. Single side service for easy access for routine maintenance make this portable generator a favorite for construction sites. Nearly impossibly to find over 12,000 Watts in a liquid-cooled diesel generator with these compact dimensions and yet a very comfortable decibel rating, makes this unit the best of all possibly worlds. You can easily carry on a conversation within yards of this fully functional generator. Plus, it's completely assembled in America by Kubota Engines.
Model Number | GL14000 |
Manufacturer | Kubota |
Made In USA | No |
Rated Watts | 12kW |
Surge Watts | 14kW |
Rated Amps | 50 |
Voltage | 120/240V Single Phase |
Enclosure | Steel |
UL Listed | No |
Decibel Rating 7m | 68 db(A) @ 23 ft. |
Features | |
Starting System | Electric Start |
Low Oil Alert | Yes |
Receptacles | 2-120V 20 Amp GFCI Duplex 1-120/240V 50 Amp Twist Type Output Terminal Bock |
Hour Meter | Yes |
Battery Requirements | Included |
Weight | 904 lbs |
Warranty Information | |
Shipping Weight | 1003 lbs |
Features | |
Dimensions | 51.57L x 25.2W x 35.24H |
Engine | |
Engine Brand | Kubota D902 |
Engine Size | 3 Cylinder |
Cooling System | Liquid Cooled |
Alternator | |
Frequency | 60 Hz |
Fuel | |
Type | Diesel |
Gauge | Yes |
Gas Tank Size | 9.62 Gal |
Run Time | 11 Hours |
Warranty Information | |
Consumer Warranty | 2 Year Limited Warranty |
Model | |
Type | Commercial Mobile Generator |
Series Name | Lowboy II |
Shipping Dimensions | 35.24H X 51.57W X 25.2D |
Shipping Weight | 1003 lbs |
Direct engine coupling and unique cooling system enhance the GL14000’s low profile that allows it to fit in more spaces. Easy One-Side Maintenance All maintenance locations can be accessed from a single, large access panel on the side of the generator: oil gauge, oil filter, oil fill, fuel filter, radiator water tank, battery and air cleaner. Engine oil and coolant drain extensions are included to help with regularly scheduled fluid changes. Most generators provide either receptacles or terminals. The GL14000 includes both.
Powered by a Kubota D902 3-cylinder water-cooled diesel with indirect injection and rated for 12kW and a maximum surge capacity of 14kW, the GL14000 120/240-Volt 60 Hertz single-phase generator has an integrated 9.6-gallon fuel tank for up to 15 hours run time at 25 percent load. The GL14000 includes Engine Shutdown for Low Oil Pressure, High Coolant Temps, Improper Charging, or High Engine Speed.
- Kubota Z902 Compact, Vertical, Liquid-Cooled, Naturally-Aspirated, 4-Cycle, 3-Cylinder Diesel engine
- Single-Phase, Three-Wire, 60Hz, 120/240VAC output power
- Electric Start with 12VDC, 28Ah Battery (38B20R). Battery is included.
- 9.62 Gallon Fuel Tank capacity forup to 11 hours of use at 50% Load (7 hours at 100% Load)
- Starter Safety Relay included to prevent accidental starting after the engine has already fired up
- The GL14000 model comes complete with Receptacles AND has the Terminal Lugs
- Terminal Size M8; Single Phase, 3-Wire (U-N/G-W)
- Emergency Stop standard via opening of either Control Panel or Terminal Cover
- Rotating field, brushless alternator
- Lifting Eye Standard on all GL models
- EPA Tier 4 Final and CARB (California Air Requirements Board) compliant
